Description
New Magenta Ink
Equipped with newly formulated magenta ink, these printers achieve excellent red colour development. The printers produce highly visible posters, making it possible to create attention-grabbing retail POPs and engaging office displays. The use of pigment ink for all colours helps to ensure that prints do not easily fade over time, making them suitable for long-term display, and also provides water resistance for outdoor use.
Colour Calibration
The ability to calibrate your printer for consistent colour quality is now available in the imagePROGRAF TM Series. This helps ensure your output is colour consistent over time and across multiple TM Series devices.
Speed
With the new L-COA PRO II processor, the new imagePROGRAF TM Series is approximately
30 percent faster than previous models with a speed of up to 3.2 ppm for an Arch D size sheet (24” x 36”).
Ease of Use
The newly designed imagePROGRAF TM Series has been built for more efficiency and comfort compared to previous models with its new flat-body design, fullfrontal operation, and new 4.3” adjustable user interface screen. The user interface screen displays the ink levels and sub-ink tank levels, media indicator levels, and other setting prompts all on the home screen!
Environmentally Conscious
Registered as EPEAT Gold—first in the imagePROGRAF TM Series— and as ENERGY STAR certified, this series is replacing EPS packaging materials with cardboard packaging.
Automatic Paper Detection
The new imagePROGRAF TM Series is able to determine the media type, length, and width, and displays this information on the user interface home screen.
Available Software – Including Poster Creation!
PosterArtist (Online and Lite versions) is an easyto- use, cost-free, template-driven poster creation software. Create professional posters, banners, flyers, and more in just four easy steps!
Free Layout Plus lets you nest, tile, and create custom layouts before printing your files with this print utility. Use the plug-in feature to print directly from Microsoft Office programs.
Direct Print Plus lets you batch print files and monitor the status of more than one imagePROGRAF Series printer. Additional features allow you to easily produce collated sets, drag and drop PDF files, and nest images.
Accounting Manager helps track actual ink and media usage and costs.
Printer Specifications
| Output Width | 36″ |
| Ink Colour Set | 5 Colour Pigment Inks: MBK/BK/C/M/Y |
| Available Ink Tank Size | 130 ml/300 ml |
| Hard Drive | 500 GB |
| Basket | Flat Stacking Basket |
| Maximum Print Speed | 3.2 D/min |
| Maximum Print Speed in Seconds | 17 Seconds |
| Maximum Print Resolution | 2,400 x 1,200 dpi |
| Total Number of Nozzles | 15,360 nozzles (MBK 5,120 nozzles, Other Colours 2,560 nozzles each) |
| Printer Memory | RAM: 128 GB (Virtual) / 2 GB (Physical)
Hard Drive: 500 GB Encrypted |
| Connectivity | Standard (Built-in): USB 2.0 Hi-Speed, 10/100/1000Base-T/TX, Wireless LAN (IEEE 802.11 b/g/n)
Direct USB Thumb Drive |
| Operating System | Windows & macOS |
| Software/Utilities/Applications | Printer Driver
PosterArtist Direct Print Plus Free Layout Plus Media Configuration Tool Accounting Manager Quick Toolbox Canon PRINT Inkjet/SELPHY Canon Print Service |
Scanner Specs
| Maximum Optical Resolution | Up to 1,200 dpi |
| Maximum Scan Width | 36″ |
| Maximum Document Width | 38” |
| Minimum Scan Width | 6.2” |
| Minimum Scan Length | 3.2” |
| Maximum Scan Length | 314” (JPEG/PDF), 598” (TIFF) |
| Scan to Copy Speed | B&W: 13.0ips Colour: 6.0ips |
| Maximum Media Thickness | 0.003” – 0.04” (0.07 mm – 1.0 mm) |
| Accuracy | 0+/- 0.1% : +/- 1 pixel |
| Software | SmartWorks MFP |
Operation Panel
| Display | 15.6″ Touchscreen Controller |
